Technical data
| Diameter range (Ø) | 30,9 up to 52,8 mm |
| Adjustment range (V) | -0.1 up to +0.4 mm |
| Rolling depth | "unlimited" over sleeve |
| Standard fixture (D) | cylindrical shank Ø 10–20 mm; Morse taper 1–2 |
| Tailor made fixture | VDI, HSK etc. |
| Internal coolant | optional |
Parameters
| Workpiece allowance | up to 0.02 mm |
| Tool preclamping | up to 0.05 mm |
| Rotation direction of tool | clockwise rotation (M3) |
| Return traverse | in rapid traverse (G0) |
| Lubrication | Emulsion or oil; filtering the lubricant (< 40 μm) can improve the surface quality and service life of the tool. |
| Pre-machining of workpiece | Surface roughness up to Rz 15 µm, tolerance IT 8 or better |
| Workpiece hardness | 45 HRC |
