Technical data
| Diameter range (Ø) | 4.9 up to 20.8 |
| Adjustment range (V) | -0.1 up to +0.2 |
| Length/Rolling depth up to Ø 7 | 29/49 mm |
| Length/Rolling depth from Ø 8 | 29/49/99 mm |
| Standard fixture (D) | cylindrical shank Ø 10–20 m Morse taper 1–4 |
| Tailor made fixture | VDI, HSK etc. |
| Internal coolant | optional from Ø 8 mm |
Parameters
| Workpiece allowance | up to 0.02 mm |
| Tool preclamping | up to 0.05 mm |
| Rotation direction of tool | clockwise rotation (M3) |
| Return traverse | in rapid traverse (G0) |
| Lubrication | Emulsion or oil; filtering the lubricant (< 40 μm) can improve the surface quality and service life of the tool. |
| Pre-machining of workpiece | Surface roughness up to Rz 15 µm, tolerance IT 8 or better |
| Workpiece hardness | 45 HRC |
