Technical data
| Diameter range (Ø) | 4.0 up to 4.9 mm |
| Adjustment range (V) | -0.05 up to +0.1 mm |
| Length | 48 mm |
| Rolling depth | 43 mm |
| Standard fixture (D) | cylindrical shank Ø 10–20 mm; Morse taper 1–3 |
| Tailor made fixture | VDI, HSK etc. |
Parameters
| Workpiece allowance | up to 0.01 mm |
| Tool preclamping | up to 0.03 mm |
| Rotation direction of tool | clockwise rotation (M3) |
| Return traverse | in rapid traverse (G0) |
| Lubrication | Emulsion or oil; filtering the lubricant (< 40 μm) can improve the surface quality and service life of the tool. |
| Pre-machining of workpiece | Surface roughness up to Rz 15 µm, tolerance IT 8 or better |
| Workpiece hardness | 45 HRC |
