Technical data
| Application | shafts, contours, recess grooves, plane surfaces |
| Standard fixture | square shank 20/25/32/40 mm |
| Swiveling range | ±90 ° in 15 °-steps adjustable |
| Radius (R) | 2 mm |
| Tailor made fixture | VDI, HSK etc. |
| Tailor made rollers | eg. carbide |
Parameters
| Speed | up to 200 mm/min |
| Feed rate | 0.05–0.3 mm/U |
| Workpiece allowance | up to 0.02 mm |
| Tool preclamping | up to 1 mm |
| Lubrication | Emulsion or oil; filtering the lubricant (< 40 μm) can improve the surface quality and service life of the tool. |
| Pre-machining of workpiece | Surface roughness up to Rz 15 µm |
| Workpiece hardness | 45 HRC |
