Single roller burnishing tool, modular system

Piktogramm Außenbearbeitung Kegel
Piktogramm Außenbearbeitung Bund
Piktogramm Außenbearbeitung Planfläche
Piktogramm Innenbearbeitung Durchgangsbohrung

Technical data

Application cylindrical shafts also against shoulder; (1 roll in use at a time)
Diameter range (Ø) from 15 mm
Tailor made fixture VDI, HSK etc.
Diameter range (Ø)

Parameters

Speed up to 200 mm/min
Feed rate up to 1 mm/U
Tool preclamping up to 1.2 mm
Workpiece allowance up to 0.02 mm
Lubrication Emulsion or oil; filtering the lubricant (< 40 μm) can improve the surface quality and service life of the tool.
Pre-machining of workpiece Surface roughness up to Rz 15 µm
Workpiece hardness 45 HRC

Modular single-roller burnishing tool system. Rolling unit for smoothening and work hardening shafts. Processing cylindrical shafts also against shoulder.

ADVANTAGES

  • Easy to use
  • Rugged tool design
  • Slim design
  • Fast feedrate possible
  • Low wear part costs
  • High surface quality > Rz 1 μm


TIP
The occuring forces can be very high! For safety reasons always ensure a sufficient clamping of the workpiece and tool on your machine.
