Diamond burnishing tool for internal use, fixed

Baublies Diamant-Glättwerkzeug starr für die Innenbearbeitung zum Glätten und Verfestigen von Bohrungen ab Ø 4 mm und Konturen
Piktogramm Innenbearbeitung Durchgangsbohrung
Piktogramm kleiner HRC60
Piktogramm Innenbearbeitung Kegel
Piktogramm Innenbearbeitung Kontur
Piktogramm Innenbearbeitung Sackloch
Piktogramm Innenbearbeitung Stufenbohrung

Technical data

Application machining of holes from Ø 4 mm and contours
Standard fixture (D) cylindrical shank Ø 6 mm with clamping surface
Diameter range (Ø) from 4 mm
Length (T) as required
Tailor made fixture Weldon, Whistle-Notch

Parameters

Speed up to 150 mm/min
Feed rate 0.05–0.2 mm/U
Workpiece allowance up to 0.015 mm
Lubrication Emulsion or oil; filtering the lubricant (< 40 µm) can improve the surface quality and service life of the tool.
Pre-machining of workpiece Surface roughness up to Rz 6 µm
Suitable for hard machining

Diamond burnishing tools for internal use are non-intrinsic (fixed not spring loaded) tools for smoothening and work hardening of holes and contours.

ADVANTAGES

  • Universally useable
  • Suitable for hard machining and thinwalled workpieces
  • Slim design enables the application in small spaced machine tools
  • Changeable diamond insert depending on the tool design
  • Re-grinding of the diamond is possible depending on the tool design
