Diamond burnishing for machinng of plane surfaces

Baublies Diamant-Glättwerkzeug zum Glätten und Verfestigen von Planflächen
Piktogramm Außenbearbeitung Planfläche
Piktogramm Innenbearbeitung Planfläche

Technical data

Application burnishing plane surfaces
Standard fixture cylindrical shank Ø 16/20/25 mm

Parameters

Speed up to 50 mm/min
Feed rate up to 0.05 mm
Workpiece allowance up to 0.01 mm
Tool preclamping up to 1 mm
Workpiece hardness > 60 HRC
Suitable for hard machining

Shape bound tool for smoothening and strain hardening of plane surfaces.

ADVANTAGES

  • Simple to use
  • Compact design available for machines with limited tool space
  • Universally applicable
  • Tolerance compensation through spring-loaded design
  • Changeable diamond insert
  • Cost-effective/ low investment
